SAPPHIRE TOXIC AMD Radeon™ RX 6900 XT Extreme Edition

11308-08-20G

Powerhouse Performance For 4K Gaming

Be the first to review this product

Description

The long envisioned and highly anticipated TOXIC AMD Radeon™ RX 6900 XT Extreme Edition Graphics Card designed for the DIY Enthusiast, and Gamer pursuing unrivaled performance with a paramount cooling solution. Driving an innovative overclocking solution with incredible new cooling technology, the TOXIC AMD Radeon™ RX 6900 XT Extreme Edition is the superior choice for building a powerhouse PC with the best gaming performance on the market.

Product Specifications

Engine Clock	Boost Clock: Up to 2525 MHz Game Clock: Up to 2375 MHzOne Click TOXIC BOOST Up to 2730 MHzBoost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads.Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.
Stream Processors	5120
Infinity Cache	128MB
Ray Accelerators	80
Memory Size/Bus	16GB GDDR6
CHIPSET	AMD RADEON
GPU	RX 6500 XT
Memory Clock	BIOS Default: 16 Gbps Effective
Displays	Maximum 4 Displays
MEMORY SIZE	16GB
MEMORY TYPE	GDDR7
Resolution	HDMI™: 7680×4320
DisplayPort1.4:	Interface 7680×4320
Output	1x HDMI 3x DisplayPort
BIOS Support	Dual UEFI
Game Index	4K
Sapphire Features	All-In-One Liquid Cooler with 360mm Radiator Dual BIOS Max Boost TriXX Software Switch Premium Digital Power Design Fuse Protection Intelligent Fan Control Precision Fan Control Backplate with ARGB ARGB Fans ARGB AIO Cooler Fans Dual Ball Bearing Fans Hybrid Fan Blade on VRM/Memory Cooling Integrated VRM/Memory Cooling Module TriXX Supported Fan Check TriXX Boost NITRO Glow External RGB LED MB Synchronization
AMD Features	AMD RDNA™ 2 Gaming Architecture DirectX® 12 Ultimate Hardware Raytracing 7nm GPU GDDR6 Memory PCI® Express 4.0 Support AMD FreeSync™ Technology DisplayPort™ 1.4 with DSC HDMI™ Video Streaming up to 8K Radeon™ VR Ready Premium AMD FidelityFX Radeon™ Image Sharpening Radeon™ Anti-Lag Radeon™ Software Game Driver Optimizations High Performance 4K Gaming
Cooling	AIO Liquid Cooling with 360 mm radiator Two-Ball Bearing Fans
Form Factor	2.5 slot, ATX + 360mm Radiator Board 270(L)x 130(W)x 45 (H)mm Hex / Radiator 394(L) x 120(W) x 52.5 (H)mm Standard Rubber Tubing, 470(L)mm
Power Consumption	<430W
os	Linux®, Windows® 7, Windows® 10, and Windows 8.1. 64-bit operating system requiredDoes not support all features including but not limited to Hardware Raytracing
System Requirement	Minimum 850 Watt Power Supply 2 x 8-pin + 1 x 6-pin Power Connector. PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. Minimum 8GB of system memory. 16GB recommended.
Vendor Item NO	11308-08-20G
