SAPPHIRE TOXIC AMD Radeon™ RX 6900 XT Extreme Edition

11308-08-20G

Powerhouse Performance For 4K Gaming

Description

The long envisioned and highly anticipated TOXIC AMD Radeon™ RX 6900 XT Extreme Edition Graphics Card designed for the DIY Enthusiast, and Gamer pursuing unrivaled performance with a paramount cooling solution. Driving an innovative overclocking solution with incredible new cooling technology, the TOXIC AMD Radeon™ RX 6900 XT Extreme Edition is the superior choice for building a powerhouse PC with the best gaming performance on the market.

Product Specifications

Engine Clock Boost Clock: Up to 2525 MHz Game Clock: Up to 2375 MHzOne Click TOXIC BOOST Up to 2730 MHzBoost Clock is the maximum frequency achievable on the GPU running bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in application and workloads.Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.
Stream Processors 5120
Infinity Cache 128MB
Ray Accelerators 80
Memory Size/Bus 16GB GDDR6
CHIPSET AMD RADEON
GPU RX 6500 XT
Memory Clock BIOS Default: 16 Gbps Effective
Displays Maximum 4 Displays
MEMORY SIZE 16GB
MEMORY TYPE GDDR7
Resolution HDMI™: 7680×4320
DisplayPort1.4: Interface 7680×4320
Output 1x HDMI 3x DisplayPort
BIOS Support Dual UEFI
Game Index 4K
Sapphire Features
  • All-In-One Liquid Cooler with 360mm Radiator Dual BIOS
  • Max Boost
  • TriXX Software Switch
  • Premium Digital Power Design
  • Fuse Protection
  • Intelligent Fan Control
  • Precision Fan Control
  • Backplate with ARGB
  • ARGB Fans
  • ARGB AIO Cooler Fans
  • Dual Ball Bearing Fans
  • Hybrid Fan Blade on VRM/Memory Cooling
  • Integrated VRM/Memory Cooling Module
  • TriXX Supported
  • Fan Check
  • TriXX Boost
  • NITRO Glow
  • External RGB LED MB Synchronization
AMD Features
  • AMD RDNA™ 2 Gaming Architecture
  • DirectX® 12 Ultimate
  • Hardware Raytracing
  • 7nm GPU
  • GDDR6 Memory
  • PCI® Express 4.0 Support
  • AMD FreeSync™ Technology
  • DisplayPort™ 1.4 with DSC
  • HDMI™
  • Video Streaming up to 8K
  • Radeon™ VR Ready Premium
  • AMD FidelityFX
  • Radeon™ Image Sharpening
  • Radeon™ Anti-Lag
  • Radeon™ Software
  • Game Driver Optimizations
  • High Performance 4K Gaming
Cooling
  • AIO Liquid Cooling with 360 mm radiator
  • Two-Ball Bearing Fans
Form Factor
  • 2.5 slot, ATX + 360mm Radiator
  • Board 270(L)x 130(W)x 45 (H)mm
  • Hex / Radiator 394(L) x 120(W) x 52.5 (H)mm
  • Standard Rubber Tubing, 470(L)mm
Power Consumption <430W
os Linux®, Windows® 7*, Windows® 10, and Windows 8.1. 64-bit operating system required*Does not support all features including but not limited to Hardware Raytracing
System Requirement
  • Minimum 850 Watt Power Supply
  • 2 x 8-pin + 1 x 6-pin Power Connector.
  • PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
  • Minimum 8GB of system memory. 16GB recommended.
Vendor Item NO 11308-08-20G
